EFB6-CS
High Speed Fixed Table Edge Sewing Machine
Application
EFB6-CS tape edge machine is mainly used for sewing mattress. A precision guide track is equipped on its support frame, which makes the walking carriage move accurately and the machine run smoothly. At the same time, its walking carriage running, sewing head tilting angle and working table height are controlled by electricity. This feature makes operation more convenient. It is a perfect equipment for manufacturing high-class mattress.
Technical data at a glance:
Model | EFB6-CS |
Corner speed auto slow down | YES |
Sewing head | Chain stitch 300U Brand Singer |
sewing head lifting range(mm) | 0-200 |
Working Table size(mm) | 1400X2000,1600X2000, 1800X2000 |
Working angle of the sewing head(degree) | 35-55 |
Sewing head motor rotory speed(r/min) | max 3065 |
Sewing thickness range of mattress(mm) | 50-500 |
carriage speed(m/min) | max.13.6 |
Carriage clutching mode | electromagnet clutch |
Productivity(pcs/hour) | 10-20 |
otal power(kw) | 1.65 |
