EHX-128
Computerized Quilting and Embroidery Machine
Application
It is widely used for quilting high-quality garments, quilt covers, hand bags, gloves, sleeping bags, pajamas, bed spreads, seat covers, plus material and household ornaments
● This kind of machine can choose any single needle to work independently so that it can change pattern simpler and quicker
● Needle bar stand is adopted to single needle bar stand based, it can change any single needle bar independently so that it
will bring more convenient for maintenance and repair
● The head of driving needle device is controlled by swinging device without cam driving and no need to maintenance . all parts are servo driving, it is durable, precise and with strong driving
● It is can sew back without manual, easy to operate, to understand and to train
● Needle stitch is proportionate, smooth and beautiful.
● Automtaic needle-lifting and digital speed adjustment
Video
Technical data at a glance:
Model | EHX-128 |
Quantity of needle head (pcs) | 66 |
Needle distance(mm) | 50.8 |
Max quilting and embroidery width (mm) | 3400 |
Working speed of main shaft (rpm) | 800 |
Stitch length(mm) | 0.15-12.7 |
X-axis movement displacement(mm) | 408 |
Stitch(mm) | 2-7 |
Total power(kw) | 5.5 |
