ELX-103
Border Four head Dotting Machine
Application
● Adopt 4 Japanese shuttle sewing heads that can work together or separately, which provides more efficient productivity.
● Professional control system, programmable design interface, touch-screen control, easy to operate.
● Able to move to left or right along X, roller cloth feeding and adopts servo and stepping motors ensuring more precision.
● 16-axle full-automatic control, can be fully automatic or separate axle controlled, with pattern sewing of high precision.
● Automatic thread cutting without any thread residue.
● Automatic cloth receiving and feeding device in synchronous movement.
● Able to design according to the patterns of clients.
Video
Technical data at a glance:
Model | ELX-103 |
Maximum speed (RPM) | 2000 |
Sewing width (mm) | ≤400 |
Sewing thickness (mm) | ≤30 |
Output (m/min) | 1-5 |
Needle stitch (mm) | 4-6 |
Total Power(kw) | 3 |
